NANO Dual-Antenna RTK Receiver
NANO Dual-Antenna RTK Receiver
The NANO Dual-Antenna RTK Receiver is the latest high-precision RTK/Heading receiver based on a new generation GNSS SoC. It can simultaneously track all visible navigation satellites, including GPS, QZSS, BDS, GALILEO, GLONASS, and IRNSS.
The NANO-HED10L supports power supply and communication through a Type-C USB or a 6P 1.25mm pitch connector.
It perfectly supports RTK and Movingbase (Heading) applications with Ardupilot or PX4 protocols.
Ordering Information
SKUConfiguration
NANO-HED10L-00
RTK/Heading, Type-C, 6P connector, w/o antenna
Specifications (Model: NANO-HED10L)
Channels128 Hardware Channels
InterfaceUSB Type-C, 6P 1.25 Connector
Frequencies
GPS: L1, L5
QZSS: L1, L5
BDS: B1, B2a
GAL: E1, E5a
QZSS: L1, L5
BDS: B1, B2a
GAL: E1, E5a
Accuracy
RTK(H): 10mm + 1 PPM
RTK(V): 30mm + 1 PPM
Heading: 0.1° / 1 m
RTK(V): 30mm + 1 PPM
Heading: 0.1° / 1 m
RTK Initialization< 10 s
Update Rate5 Hz (Default)
Serial PortsUART * 2
Antenna ConnectorSMA * 2 (Master & Slave RTK)
Power Supply4.75 〜 5.25 V
Dimensions65 * 36 mm
Current Consumption~ 200 mA
Weight13 g
