MA-10P-v2 Series

A high-precision GNSS PPP receiver based on the D10P module, specifically supporting Japan’s QZSS PPP service. It tracks GPS/QZSS, GALILEO, BDS, and GLONASS on L1/L5 frequencies.

Within the QZSS service coverage area, including major parts of the Asia-Pacific region and Australia as shown in the coverage map below, the receiver enables convenient real-time PPP positioning without requiring any local correction service. After initialization and convergence, PPP positioning accuracy can typically reach 0.1–0.6 m. Outside the QZSS service coverage area, PPP positioning can be achieved through network-based correction services, such as NTRIP.

With its built-in positioning engine, it enables robust PPP positioning based on MADOCA services, making it ideal for various positioning projects within the service coverage area.

The MA10P-V2 supports both Bluetooth Low Energy (BLE) and USB connectivity, and can also output positioning data via a serial interface.

It is compatible with a wide range of popular GIS and field data collection applications.

Supported Software

• SW Maps – Free GIS and mobile mapping app for geographic data collection, mapping, KML, shapefiles, and more.
• QField – Professional mobile GIS application for field surveying, geospatial data collection, and management.
• ROLAVICam – Mobile capture application for photogrammetry, videogrammetry, and field documentation.

Package Contents

• MA10P-V2 GNSS Receiver
• AT400 Full-Band GNSS Antenna
• 1.5m RF cable for antenna
