PocketSDR GNSS receiver
P/N
Status
PocketSDR-8CH
Out of Stock
PocketSDR-4CH
In Stock
If you want to know the latest inventory information, please join our WhatsApp community or follow our Telegram channel.
For custom orders or further details, please email: info@datagnss.com
PocketSDR GNSS Receiver
This is a commercial implementation of Prof. T. Takasu's open-source project PocketSDR on GitHub. Manufactured in strict accordance with the original open-source schematics, this device is the 4-channel version equipped with 4x MAX2771 RF front ends.
It supports almost all GNSS frequency bands and global satellite navigation systems.
Pocket SDR FE 4CH is an open-source GNSS SDR RF frontend device for Pocket SDR. The device consists of 4 CH Maxim MAX2771 GNSS RF front-end ICs (LNA, mixer, filter, ADC, frequency synthesizer) and a Cypress EZ-USB FX3 USB 3.0 controller to connect to host PCs. All the RF CHs are able to be configured for GNSS L1 band (1525 - 1610 MHz), or GNSS L2/L5/L6 band (1160 - 1290 MHz). The frequency of the reference oscillator (TCXO) is 24.000 MHz, and the ADC sampling rate can be configured up to 48 Msps.
Specifications
- Number of RF channels: 4 CH
- LO (PLL) Frequency: 1525 ~ 1610 MHz (GNSS L1 band) or 1160 ~ 1290 MHz (GNSS L2/L5/L6 band)
- IF Bandwidth: 2 ~ 36 MHz
- Sampling Rate: 4, 6, 8, 10, 12, 16, 20, 24, 32, 40 or 48 Msps
- Sampling Type: I or I/Q sampling, 2 bits resolution
- Host I/F: USB 3.0, Type-C (High-speed 480 Mbps / SuperSpeed 5 Gbps)
- Power: 5V, USB bus power
